HARDWARE FEATURES |
|
Interface |
One(1) 2.5Gbps WAN Ethernet Port
Three(3) 1Gbps LAN Ethernet Ports |
|
Button |
Reset Button, Power On/Off Button,Mesh Button |
|
External Power Supply |
12V/2A |
|
Dimensions ( W x D x H ) |
100*100*200 mm |
|
Environment |
Operating Environment: 0~40°C, 10%～90% non-condensing
Storage Environment: -40~70°C, 5%～95% non-condensing |
|
Antenna |
Built-in 5G/LTE primary antenna
Built-in 5G/LTE secondary antenna
Built-in Wi-Fi 2.4GHz/5GHz antennas |
|
WIRELESS FEATURES |
|
Wireless Standards |
IEEE 802.11a/n/ac/ax 5 GHz, IEEE 802.11b/g/n/ac/ax 2.4 GHz |
|
Frequency |
2.4 GHz and 5 GHz |
|
Signal Rate |
574Mbps at 2.4 GHz, 2402Mbps at 5 GHz |
|
Wi-FiMax.AssociatedClients |
256 |
|
WAN Failover |
Yes |
|
Wireless Security |
WPA/WPA2, WPA-PSK |
|
Modulation technology |
OFDM: BPSK@6/9Mbps, QPSK@12/18Mbps, 16QAM@24Mbps, 64QAM@48/54Mbps
DSSS: DBPSK@1Mbps, DQPSK@2Mbps, CCK@5.5/11Mbps
MIMO-OFDM: MCS 0-31
MIMO-OFDM (11ac): MCS 0-9
MIMO-OFDMA (11ax): MCS 0~9 |
|
CELLULAR FEATURES |
|
Module |
RM520-GL |
|
Band |
5G NR:3GPP Release 16 NSA/SA operation, Sub-6 GHz
Sub-6 NSA Band:
n1/2/3/5/7/8/12/13/14/18/20/25/26/28/39/30/38/40/41/48/66/70/71/75/76/7
7/78/79
Sub-6 SA Band:
n1/2/3/5/7/8/12/13/14/18/20/25/26/28/39/30/38/40/41/48/66/70/71/75/76/7
7/78/79
Max. Sub-6 BW:120MHz
Sub-6 CA:FDD+FDD,TDD+TDD,FDD+TDD DL2CA/UL 2CA
DL 4x4 MIMO:n1/2/3/5/7/25/30/38/40/48/66/70/77/78/79
UL 2x2 MIMO:n38/41/48/77/78/79 |
|
Data Speed |
5G SA Sub-6 Max:DL 2.4 Gbps; UL 900 Mbps
5G NSA Sub-6 Max:DL 3.4 Gbps; UL 550 Mbps
LTE Max:DL 1.6 Gbps; UL 200 Mbps
WCDMA Max:DL 42 Mbps; UL 5.76 Mbps |
|
SOFTWARE FEATURES |
|
Channel adjustment |
Support |
|
Power adjustment |
Support |
|
Mesh |
Support NRadio N-Mesh networking function |
|
Access restrictions |
Support |
|
SSID Hidden |
Support |
|
Speed limitation |
Support |
|
Black and white list |
Support |
|
User isolation |
Support |
|
Bandwidth limit |
Support |
|
DHCP |
Support |
|
VPN |
Support |
|
NRadio Cloud |
Support NRadio Connection and realize remote management. |
